background image
Copyright © 2014 Future Technology Devices International Limited
25
Document No.: FT_000648
FT121 ENHANCED USB DEVICE CONTROLLER WITH SPI SLAVE IC
Datasheet Version 1.2
Clearance No.: FTDI#
312
6.3 Data Flow Commands
6.3.1 Read Interrupt Register
Command
: F4h
Data
: Read 1 or 2 bytes (Default Mode); Read 1-4 bytes (Enhanced Mode)
Bit
Symbol
Reset
Description
0
Endpoint 0 Out
0
Interrupt for endpoint 0 OUT buffer. Cleared by Read
Last Transaction Status command.
1
Endpoint 0 In
0
Interrupt for endpoint 0 IN buffer. Cleared by Read Last
Transaction Status command.
2
Endpoint 1 Out
0
Interrupt for endpoint 1 OUT buffer. Cleared by Read
Last Transaction Status command.
3
Endpoint 1 In
0
Interrupt for endpoint 1 IN buffer. Cleared by Read Last
Transaction Status command.
4
Endpoint 2 Out
0
Interrupt for endpoint 2 OUT buffer. Cleared by Read
Last Transaction Status command.
5
Endpoint 2 In
0
Interrupt for endpoint 2 IN buffer. Cleared by Read Last
Transaction Status command.
6
Bus Reset
0
Interrupt for bus reset. This bit will be cleared after
reading.
7
Suspend Change
0
Interrupt for USB bus suspend status change. This bit
will be set to ‘1’ when FT121 goes to suspend (missing 3
continuous SOFs) or resumes from suspend. This bit will
be cleared after reading.
Table 6.9 Interrupt Register Byte 1
Bit
Symbol
Reset
Description
7-0
Reserved
00h
Reserved
Table 6.10 Interrupt Register Byte 2
Bit
Symbol
Reset
Description
0
Endpoint 3 Out
0
Interrupt for endpoint 3 OUT buffer. Cleared by Read
Last Transaction Status command.
1
Endpoint 3 In
0
Interrupt for endpoint 3 IN buffer. Cleared by Read Last
Transaction Status command.
2
Endpoint 4 Out
0
Interrupt for endpoint 4 OUT buffer. Cleared by Read
Last Transaction Status command.
3
Endpoint 4 In
0
Interrupt for endpoint 4 IN buffer. Cleared by Read Last
Transaction Status command.
