53 / 105 page

Figure 30 : Entering and Exiting Low Power Mode (example is 4wire mode).

D[3:0]

CLKI

Frame

Number

SDA

SCL

Start of Frame Line for the 1st

frame of valid video data.

Valid Video data.

setup0[0]

LP0-LP1

“Enter Low Power Mode” Command.

LP2

At end of current frame, the sensor will enter the low power mode and the databus will be driven high.

LP3-LP4

“Exit Low Power Mode” Command sent to sensor - sensor begins power up sequence.

LP5-LP6

1 Frame of alternating 9H & 6H data on D[3:0] for the host to determine the best sampling phase for the nibble data (D[3:0]).

LP7-LP8

4 Frames after the “Exit low Power Mode” command, the sensor starts outputing valid video data.

One frame of 9H &6H data.

9H,6H,9H,6H...
