CC2500

PRELIMINARY Data Sheet (Rev.1.2)

SWRS040A

Page 21 of 83

10.1

Chip Status Byte

When the header byte, data byte or command

strobe is sent on the SPI interface, the chip

status byte is sent by the

CC2500 on the SO

pin. The status byte contains key status

signals, useful for the MCU. The first bit, s7, is

the CHIP_RDYn signal; this signal must go low

before the first positive edge of SCLK. The

CHIP_RDYn

signal indicates that the crystal is

running and the regulated digital supply

voltage is stable.

Bits 6, 5 and 4 comprise the STATE value.

This value reflects the state of the chip. The

XOSC and power to the digital core is on in

the IDLE state, but all other modules are in

power down. The frequency and channel

configuration should only be updated when the

chip is in this state. The RX state will be active

when the chip is in receive mode. Likewise, TX

is active when the chip is transmitting.

The last four bits (3:0) in the status byte con-

tains FIFO_BYTES_AVAILABLE. For read

operations,

the

FIFO_BYTES_AVAILABLE

field contains the number of bytes available for

reading from the RX FIFO. For write

operations,

the

FIFO_BYTES_AVAILABLE

field contains the number of bytes free for

writing

into

the

FIFO.

When

FIFO_BYTES_AVAILABLE=15

, 15 or more

bytes are available/free.

Table 17 gives a status byte summary.

Bits

Name

Description

CHIP_RDYn

Stays high until power and crystal have stabilized. Should always be low when using

the SPI interface.

6:4

STATE[2:0]

Indicates the current main state machine mode

Value

State

Description

000

IDLE

Idle state

(Also reported for some transitional states instead

of SETTLING or CALIBRATE)

001

Receive mode

010

Transmit mode

011

FSTXON

Frequency synthesizer is on, ready to start

transmitting

100

CALIBRATE

Frequency synthesizer calibration is running

101

SETTLING

PLL is settling

110

RXFIFO_OVERFLOW

RX FIFO has overflowed. Read out any

useful data, then flush the FIFO with SFRX

111

TXFIFO_UNDERFLOW

TX FIFO has underflowed. Acknowledge with

SFTX

3:0

FIFO_BYTES_AVAILABLE[3:0]

The number of bytes available in the RX FIFO or free bytes in the TX FIFO

(depends on the read/write-bit). If FIFO_BYTES_AVAILABLE=15, there are 15 or

more bytes in RX FIFO or 49 or less bytes in the TX FIFO.

Table 17: Status byte summary

10.2

The configuration registers of the

CC2500 are

located on SPI addresses from 0x00 to 0x2F.

Table 35 on page 52 lists all configuration

registers. The detailed description of each

page 55. All configuration registers can be

both written to and read. The read/write bit

controls if the register should be written to or

read. When writing to registers, the status byte

is sent on the SO pin each time a header byte

or data byte is transmitted on the SI pin.

When reading from registers, the status byte is

sent on the SO pin each time a header byte is

transmitted on the SI pin.

Registers with consecutive addresses can be

accessed in an efficient way by setting the
