MPZ2012S221A 数据表(PDF) 46 Page - STMicroelectronics

部件名 MPZ2012S221A
功能描述  38 V, 10 W synchronous iso-buck converter for isolated applications
PDF  56 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
制造商  STMICROELECTRONICS [STMicroelectronics]
网页  http://www.st.com
标志 STMICROELECTRONICS - STMicroelectronics

MPZ2012S221A 数据表(HTML) 46 Page - STMicroelectronics

Back Button MPZ2012S221A Datasheet HTML 42Page - STMicroelectronics MPZ2012S221A Datasheet HTML 43Page - STMicroelectronics MPZ2012S221A Datasheet HTML 44Page - STMicroelectronics MPZ2012S221A Datasheet HTML 45Page - STMicroelectronics MPZ2012S221A Datasheet HTML 46Page - STMicroelectronics MPZ2012S221A Datasheet HTML 47Page - STMicroelectronics MPZ2012S221A Datasheet HTML 48Page - STMicroelectronics MPZ2012S221A Datasheet HTML 49Page - STMicroelectronics MPZ2012S221A Datasheet HTML 50Page - STMicroelectronics Next Button
Zoom Inzoom in Zoom Outzoom out
 46 / 56 page
background image
Reference
Part number
Description
Value
Manufacturer
R3
0603 SMD resistor
Not mounted (330 Ω)
C1
0603 MLCC
Not mounted (1 µF, 35 V)
Ciso+, Ciso-
0805 MLCC
Not mounted (1 µF, 50 V)
Dz1
Zener diode
Not mounted (Vz1 = 12
V)
Dz2
4.7 V Zener diode
Not mounted (Vz1 = 4.7
V)
Q1
2STR1215
NPN power transistor
Not mounted
ST
Figure 52. STEVAL-L6983IV1 (top layer)
Figure 53. STEVAL-L6983IV1 (bottom layer)
L6983I
Application board
DS14040 - Rev 1
page 46/56
