 22 / 56 page
background image
Figure 26. Secondary output efficiency vs. switching frequency (VIN = 12 V, VOUT_prim = 5 V, N = 6)
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
0
0.05
0.1
0.15
0.2
0.25
0.3
Isolated output current [A]
fsw = 200 kHz
fsw = 400 kHz
fsw = 700 kHz
Selecting a lower switching frequency impacts however on the transformer size and on the ripple (see Figure 27)
requiring therefore a higher output capacitance to reduce it.
Figure 27. Isolated output voltage ripple vs. switching frequency (COUTiso = 10 µF)
L6983I
Efficiency
DS14040 - Rev 1
page 22/56
