WINCS02IC and WINCS02 Family

Device Overview

Data Sheet

DS70005577B - 24

The following figures illustrate the 2D cross section of the antenna radiation pattern.

Figure 2-18. Antenna Radiation Azimuth Plane Pattern when Theta = 90°

Azimuth (°)

90° 2400.00 MHz Polar H

90° 2400.00 MHz Polar V

Figure 2-19. Antenna Radiation Elevated Plane Pattern when Phi = 0°

Elevation (°)

0° 2400.00 MHz Polar H

0° 2400.00 MHz Polar V
