MB96F348CWCPMC-GSE2 数据表(PDF) 69 Page - Cypress Semiconductor |
|
|
|||||||||||||||||||||||||||||
MB96F348CWCPMC-GSE2 数据表(HTML) 69 Page - Cypress Semiconductor |
|
|
69 / 109 page  MB96340 Series Document Number: 002-04579 Rev. *A Page 69 of 109 Power supply current for active Clock modulator ICCCLOMO Clock modulator enabled (CMCR:PDX = 1) -3 4.5 mA Must be added to all current above Flash Write/Erase current ICCFLASH Current for one Flash module - 15 40 mA Must be added to all current above ICCDFLASH Current for one Data Flash module 10 20 mA Must be added to all current above Input capacitance CIN -- 5 15 pF Other than C, AVCC, AVSS, AVRH, AVRL, VCC, VSS [1]: The power supply current is measured with a 4MHz external clock connected to the Main oscillator and a 32kHz external clock connected to the Sub oscillator. See chapter “Standby mode and voltage regulator control circuit” of the Hardware Manual for further details about voltage regulator control. (TA = -40°C to 125°C, VCC = AVCC = 3.0V to 5.5V, VSS = AVSS = 0V) Parameter Symbol Condition (at TA) Value Remarks Typ Max Unit |
|
