MB96340 Series
Document Number: 002-04579 Rev. *A
Page 13 of 109
5. Pin Circuit Type
[1]: Please refer to “ I/O Circuit Type” for details on the I/O circuit types
[2]: Devices with suffix ”W”
[3]: Devices without suffix ”W”
Table 2: Pin circuit types
FPT-100P-M20
FPT-100P-M22
Pin no.
Circuit
type [1]
Pin no.
Circuit
type [1]
1-10
H
1-12
H
11,12
B [2]
13, 14
B [2]
11,12
H [3]
13, 14
H [3]
13,14
Supply
15,16
Supply
15
F
17
F
16,17
H
18,19
H
18-21
N
20-23
N
22-29
I
24-31
I
30
Supply
32
Supply
31-32
G
33-34
G
33
Supply
35
Supply
34 to 41
I
36 to 43
I
42
Supply
44
Supply
43 to 48
I
45 to 50
I
49 to 51
C
51 to 53
C
52
E
54
E
53 to 54
I
55 to 56
I
55 to 62
H
57 to 64
H
63, 64
Supply
65, 66
Supply
65 to 87
H
67 to 89
H
88,89
Supply
90, 91
Supply
90, 91
A
92, 93
A
92-100
H
94 to 100
H
