13 / 48 page  Data Sheet AD9739 Rev. B | Page 13 of 48 fDAC = 2 GSPS, IOUTFS = 20 mA, nominal supplies, 25°C, unless otherwise noted. –3dBFS 0dBFS fOUT (MHz) 30 40 50 60 70 80 90 0 100 200 300 400 500 600 700 800 900 1000 –6dBFS Figure 13. SFDR vs. fOUT over Digital Full Scale fOUT (MHz) 30 0 100 200 300 400 500 600 700 800 900 1000 40 50 60 70 80 90 0dBFS –3dBFS –6dBFS Figure 14. SFDR for Second Harmonic over fOUT vs. Digital Full Scale fOUT (MHz) 30 40 50 60 70 80 90 0 100 200 300 400 500 600 700 800 900 1000 10mA FS 20mA FS 30mA FS Figure 15. SFDR vs. fOUT over DAC IOUTFS fOUT (MHz) 30 40 50 60 70 80 90 100 110 0 100 200 300 400 500 600 700 800 900 1000 0dBFS –6dBFS –3dBFS Figure 16. IMD vs. fOUT over Digital Full Scale fOUT (MHz) 30 0 100 200 300 400 500 600 700 800 900 1000 40 50 60 70 80 90 –6dBFS –3dBFS 0dBFS Figure 17. SFDR for Third Harmonic over fOUT vs. Digital Full Scale fOUT (MHz) 30 40 50 60 70 80 90 100 110 0 100 200 300 400 500 600 700 800 900 1000 10mA FS 20mA FS 30mA FS Figure 18. IMD vs. fOUT over DAC IOUTFS |
|
