8 / 46 page  - 8 - JANURARY 18, 2013 | DATA SHEET | Rev 3.5 8 IR3898 6A Highly Integrated SupIRBuck TM Single-Input Voltage, Synchronous Buck Regulator PD-97662 PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNIT Accuracy 0°C < Tj < +70°C -0.5 +0.5 % -40°C < Tj < +125°C -1.0 +1.0 % Vref Margining Voltage Vref_marg 0.4 1.2 V Sink Current Isink_Vref Vref = 0.6V 12.7 16.0 19.3 µA Source Current Isrc_Vref Vref = 0.4V 12.7 16.0 19.3 Vref Comparator Threshold Vref_disable Vref pin connected externally 0.15 V Vref_enable 0.4 Soft Start/Stop Soft Start Ramp Rate Ramp(SS_start) 0.16 0.2 0.24 mV/µs Soft Stop Ramp Rate Ramp(SS_stop) -0.24 -0.2 -0.16 S_Ctrl Threshold High 2.4 V Low 0.6 Power Good PGood Turn on Threshold VPG(on) Vsns Rising, 0.4V < Vref < 1.2V 85 90 95 % Vref Vsns Rising, Vref < 0.1V 85 90 95 % Vp PGood Lower Turn off Threshold VPG(lower) Vsns Falling, 0.4V < Vref < 1.2V 80 85 90 % Vref Vsns Falling, Vref < 0.1V 80 85 90 % Vp PGood Turn on Delay VPG(on)_Dly Vsns Rising,see VPG(on) 1.28 ms PGood Upper Turn off Threshold VPG(upper) Vsns Rising, 0.4V < Vref < 1.2V 115 120 125 % Vref Vsns Rising, Vref < 0.1V 115 120 125 % Vp PGood Comparator Delay VPG(comp)_ Dly Vsns < VPG(lower) or Vsns > VPG(upper) 1 2 3.5 µs PGood Voltage Low PG(voltage) IPgood = -5mA 0.5 V Tracker Comparator Upper Threshold VPG(tracker_ upper) Vp Rising, Vref < 0.1V 0.4 V Tracker Comparator Lower Threshold VPG(tracker_ lower) Vp Falling, Vref < 0.1V 0.3 Tracker Comparator Delay Tdelay(tracker) Vp Rising, Vref < 0.1V,see VPG(tracker_upper) 1.28 ms Under-Voltage Lockout Vcc-Start Threshold VCC_UVLO_Start Vcc Rising Trip Level 4.0 4.2 4.4 V Vcc-Stop Threshold VCC_UVLO_Stop Vcc Falling Trip Level 3.7 3.9 4.1 Enable-Start-Threshold Enable_UVLO_Start Supply ramping up 1.14 1.2 1.26 V Enable-Stop-Threshold Enable_UVLO_Stop Supply ramping down 0.95 1 1.05 Enable Leakage Current Ien Enable = 3.3V 1 µA Over-Voltage Protection OVP Trip Threshold OVP_Vth Vsns Rising, 0.45V < Vref < 1.2V 115 120 125 % Vref |
|
