Data Sheet
ADP5014
Rev. A | Page 13 of 34
CH1 1.00V
CH2 2.00V
M 4.00ms
A CH1
820mV
1
2
3
4
T 24.20%
B
W
CH3 2.00V
CH4 2.00V
B
W
B
W
B
W
Figure 22. Startup for All Channels Under Sequence Enable Mode,
Channel 1 = VOUT1, Channel 2 = VOUT2, Channel 3 = VOUT3, Channel 4 = VOUT4
CH1 1.00V
CH2 2.00V
M 10.0ms
A CH1
780mV
1
2
3
4
T 72.00%
B
W
CH3 2.00V
CH4 2.00V
B
W
B
W
B
W
Figure 23. Shutdown for All Channels Under Sequence Enable Mode,
Channel 1 = VOUT1, Channel 2 = VOUT2, Channel 3 = VOUT3, Channel 4 = VOUT4
CH1 5.00V
CH2 500mV
M 1.00ms
A CH2
780mV
1
2
3
4
T 42.80%
B
W
CH3 5.00V
CH4 5.00A
B
W
B
W
B
W
Ω
Figure 24. Channel 1 Startup with Full Load, VIN = 5 V, VOUT = 1.2 V,
Channel 1 = EN1/ENALL, Channel 2 = VOUT1, Channel 3 = PWRGD,
Channel 4 = IOUT1
CH1 5.00V
CH2 500mV
M 20.0ms
A CH2
780mV
1
2
3
4
T 42.8%
B
W
CH3 5.00V
CH4 5.00A
B
W
B
W
B
W
Ω
Figure 25. Channel 1 Shutdown with Active Output Discharge, VIN= 5 V, VOUT =
1.2 V, fSW = 1.2 MHz, L = 0.8 µH, COUT = 47 µF × 2, Channel 1 = EN1/ENALL,
Channel 2 = VOUT1, Channel 3 = PWRGD, Channel 4 = IOUT1
CH1 500mV
CH2 5.00V
M 10.0ms
A CH1
520mV
1
2
4
T 25.60%
B
W
CH4 5.00A
B
W
Ω
Figure 26. Short-Circuit Protection Entry, VIN = 5 V, VOUT = 1.2 V, fSW = 1.2 MHz,
L = 0.8 µH, COUT = 47 µF × 2, Channel 1 = VOUTX, Channel 2 = SWX,
Channel 4 = ILX
CH1 500mV
CH2 5.00V
M10.0ms
A CH1
1.01V
1
2
4
T 80.60%
B
W
CH4 5.00A
B
W
Ω
Figure 27. Short-Circuit Protection Recovery, VIN = 5 V, VOUT= 1.2 V, fSW = 1.2 MHz,
L = 0.8 µH, COUT = 47 µF × 2, Channel 1 = VOUTX, Channel 2 = SWX,
Channel 4 = ILX
